Refuse compactor ISUZU Garbage compactor trucks

 Refuse compactor garbage truck Isuzu 4CBM (also called as compressive garbage truck, hydraulic garbage truck, rear loader garbage truck, garbage compacting truck, compactor garbage truck, waste collector truck)  is widely used in daily rubbish transport in such living areas as all kinds of cities, large station, port and whart, airpot and densely-populated areas like industrical and mineral enterprises and military units.

All our compressed garbage truck optional hanging bucket or barrel tilting mechanism, automatic operating, simple and efficient garbage collection. It can be converted into various special garbage truck according to clients' special requirement.

Features:
---- ISUZU chassis, perfect performance.
---- Compression ration > 60%
---- Compression body capacity from 3 CBM TO 20 CBM
---- Sealed transportation avoid the second time pollution
---- Massive, durable, perfect performance
Specifications:

Refuse Compactor Vehicle Isuzu (4 CBM)
General
Vehicle Brand
POWERSTAR
Chassis Brand
ISUZU
Overall Dimension
6230 * 2000 * 2490 mm
GVW / Kerb Weight
8,000kg / 4,890kg
Cab
Cab Capacity
2 persons allowed
Air Conditioner
Heating/cooling air conditioner
Engine
Fuel Type
Diesel
Engine Brand
ISUZU
Power
98 HP (72 KW)
Displacement
2777ml
Emission Standard
Euro IV or V
Chassis
Drive Type
4X2, (left hand drive)
Transmission
ISUZU MSB 5 speed levers with 1 reverse
Wheelbase/No. of axle
3360 mm / 2
Tire Specification
7.00-16
Tire Number
6 tires and 1 spare tire
Max Speed
95 km/h
Paint
Metallic paint
Superstructure
Body Capacity
4 CBM
Fill Hopper Capacity
0.8 m3
Sewager Tank volume
200 L
Body Material
Weather resisting steel
Filling work cycle time
20~25 s
Filling lift time
6~9 s
Filling lift capacity
8 Tons
Discharge time
18~22 s
Max compression force
12 Tons
Discharge model
Horizontal Ejection
Control
Electrically Hydraulic control
Manual Hydraulic control
Emergency Stop Button
Hopper Both Sides
All standard accessories: Warning lights, music alarm, basic tool kit, English manual……
Optional
** Backup alarm can be equipped.
** Camera can be equipped.
** Operation language can be English or Appointed language.

  technical drawing for 3 Ton Isuzu Garbage Truck With Compactor

Working Principles of Garbage Compactor
Technical drawing for Isuzu NPR Refuse compactor (Garbage compactor truck)
Different bin optional:

 bin hopper for garbage compactor truck
 bin hopper for garbage compactor truck

 bin hopper for garbage compactor truck  bin hopper for garbage compactor truck

Detail pictures:
