ISUZU Fire Trucks, ISUZU Fuel/Water Tanker Trucks, Isuzu Road Sweeper, ISUZU Garbage compactor truck: Isuzu GIGA Truck Mounted Combination Jet Suction Units

Isuzu GIGA Truck Mounted Combination Jet Suction Units is equipped with FVR 5X 4X2 chassis, 240HP engine, 2500L clean water tank, 6000L vacuum tank. It combines high-pressure jetting and suction functions, can efficiently handle pipeline cleaning and liquid transfer tasks, and is an important tool in the field of modern cleaning and waste disposal.

Isuzu GIGA Truck Mounted Combination Jet Suction Units also called Isuzu GIGA combined vacuum jetting truck,Isuzu FVR GIGA combination jetter truck,Isuzu FVR 5X chassis sewer jetting and vacuum truck,Isuzu VC61 hydro jetting drain cleaning truck,Isuzu new FVR vacuum truck with jet cleaner,Isuzu 4x2 combined sewer cleaner truck. The Isuzu GIGA Truck Mounted Combination Jet Suction Units is a high-end professional cleaning equipment launched by Isuzu. It combines efficient dirt suction with powerful water gun spraying, and is suitable for a variety of scenarios such as urban sanitation, industrial cleaning, environmental protection and disaster relief. The vehicle adopts a heavy-duty chassis design with strong carrying capacity. It is equipped with an advanced vacuum pump and high-pressure water gun system, which can quickly clean up garbage, sludge and pollutants and improve cleaning efficiency. At the same time, its environmental protection and energy-saving design concept also meets the sustainable development requirements of modern society.

Isuzu giga Truck Mounted Combination Jet Suction Units

The Isuzu GIGA Truck Mounted Combination Jet Suction Units on the FVR 5X 4X2 chassis with a robust 240HP engine, a 2,500L cleaning water tank, and a substantial 6,000L vacuum tank redefine efficiency and versatility in waste management and liquid transport operations. This specialized unit integrates high-pressure jetting and suction capabilities, streamlining tasks such as pipeline cleaning and waste removal with precision and speed.

Isuzu GIGA Truck Mounted Combination Jet Suction Units
General	Truck model	PT5180GQW
	Chassis Brand	ISUZU
	Overall Dimension	8300x2500x3350 mm
	GVW / Kerb Weight	18,000 kg / 9,500 kg
Cab	Cab Capacity	One and half row,3 persons allowed
Cab	Air Conditioner	With air conditioner
Engine	Fuel Type	Diesel,6 cylinder in line
	Engine Brand	ISUZU engine 6HK1-TCG61
	Power	240HP(177KW)
	Displacement	7790 ml
	Emission Standard	Euro VI
Chassis	Drive Type	4X2, left hand drive
	Transmission	FAST 8-speed,manual
	Wheelbase/No. & axle	4500mm/ 2
	Tyre Specification	295/80R22.5
	Tyre Number	6 tyres and 1 spare tyre
	Max Speed	105 km/h
	Paint	Metallic paint
Superstructure	Tank Capacity	Tank A: 2500L cleaning water tank Tank B: 6000L vacuum tank
	Tank Material	Carbon steel
	Tank lifting angel	45 degree
	Suction time	5min
	Suction Head	7m
	Vacuum Pump	2BE-204 Water circulation vacuum pump
		Ultimate vacuum 3300 Pa
		Rpm speed：980rpm/min
		Maximum pumping speed:21m3/min
	Hose	High quality, wire strengthened hose
	Rear door can be hydraulic opened for complete discharge & solid stuff.
	All standard accessories: inlet, discharge, antifill valve.....

POWERSTAR, the manufacturer of special purpose vehicles, has launched its powerful GIGA truck mounted combination jet suction unit, a pinnacle of power, innovation and adaptability, designed to revolutionize waste management and liquid transport operations. Mounted on a rugged FVR 5X 4X2 chassis, this professional unit embodies strength and precision, ensuring optimal performance in a variety of challenging environments. Powered by a powerful 240HP engine, the Isuzu GIGA truck makes light work of tasks, increasing productivity while optimizing fuel efficiency.

Technical drawing of Isuzu GIGA mounted combination jet suction units

Isuzu giga Truck Mounted Combination Jet Suction Units

At the heart of this extraordinary machine is the Isuzu FVR 5X 4X2 chassis, the 4x2 configuration ensures optimal traction and maneuverability on a variety of terrains, while the rugged structure and high-quality components ensure a long-lasting service life. The chassis also boasts an impressive load-bearing capacity, providing a stable platform for the jet suction unit's extensive equipment.

This powerful machine is powered by a powerful 240HP engine that delivers enough torque and horsepower to meet the demanding requirements of a jet suction system. The engine is designed for efficient fuel consumption, keeping operating costs low while maintaining optimal performance levels. Its reliable operation ensures that the truck can keep up with the pace of the most intensive cleaning jobs, ensuring that tasks are completed quickly and efficiently.

Isuzu GIGA combined vacuum jetting truck

Isuzu FVR GIGA combination jetter truck

One of the standout features of the Isuzu GIGA truck-mounted combined jet suction unit is its huge 2500L cleaning water tank. This large capacity allows for long periods of operation without frequent water refilling, significantly reducing downtime and increasing productivity. The water tank is made of high-quality materials that are resistant to corrosion and wear, ensuring it remains in optimal condition even after years of frequent use. The water supply system is designed to be precise and efficient, allowing the operator to direct the high-pressure water jet exactly where it is needed, effectively loosening and removing the most stubborn dirt and debris.

The Isuzu GIGA combined vacuum jetting truck has enhanced its capabilities by integrating a vacuum tank with a capacity of 6,000L, designed to accommodate large volumes of liquid waste and debris. This vacuum tank has been carefully designed to be durable and reliable, allowing the unit to carry out a large number of operations without interruption, minimizing downtime and increasing operational efficiency. Its rugged construction ensures resilience in tough working conditions and embodies Isuzu's commitment to performance and long life. The vacuum system is equipped with an advanced filtering and separation mechanism, ensuring that only clean air is exhausted back into the environment. This not only helps protect the health and safety of operators and bystanders, but also minimizes the environmental impact of the cleaning process.

Isuzu VC61 hydro jetting drain cleaning truck

Isuzu new FVR vacuum truck with jet cleaner

The integration of a jet suction unit within the Isuzu FVR GIGA combination jetter truck heralds a new era of operational excellence and versatility. The integrated system provides a comprehensive solution for liquid waste management, allowing for efficient extraction of liquids, sludge and debris while enabling high-pressure cleaning operations. The Isuzu FVR combined sewer truck combines jetting and suction capabilities to streamline workflows, optimize productivity and ensure a thorough waste removal process.

The combination of jet suction and vacuum systems makes the Isuzu FVR sewer jetting and vacuum truck a true multi-tasker. It can handle everything from street cleaning and gutter clearing to oil spill control and industrial waste removal. The versatile design of the unit allows it to be easily adapted to specific cleaning needs, making it a valuable asset for a wide range of organizations and industries.

Isuzu 4x2 combined sewer cleaner truck

Isuzu FVR 5X chassis sewer jetting and vacuum truck

Equipped with state-of-the-art technology, the Isuzu new FVR hydro jetting drain cleaning truck prioritizes safety and performance in all aspects of operation. Integrated safety mechanisms and protocols ensure safe operation, highlighting Isuzu's dedication to user protection and operational integrity. By fostering a safe working environment, Isuzu insists on providing reliable solutions that prioritize the well-being of operators and bystanders.

Demonstrating Isuzu's unwavering commitment to quality and durability, the Isuzu GIGA vacuum truck with jet cleaner, is engineered to withstand the rigors of intensive use across different industrial sectors. The truck's robust structure ensures longevity and resilience, minimizing maintenance requirements and maximizing uptime and productivity. This durability guarantees continuous performance during long periods of operation, making the Isuzu GIGA truck a reliable asset for demanding applications.

Isuzu's dedication to sustainability is reflected in the eco-friendly design of the Isuzu FVR 240HP combined sewer cleaner truck. The unit's efficient fuel consumption and low-emission characteristics meet environmental standards, promote eco-friendly operations and reduce carbon footprint. By championing environmental stewardship, Isuzu contributes to a cleaner and healthier ecosystem, demonstrating its proactive approach to sustainability.

Isuzu FVR 240HP combined sewer cleaner truck

Isuzu GIGA Truck Mounted Combination Jet Suction Units have a wide range of application scenarios, mainly concentrated in areas that require efficient and professional cleaning and waste disposal. Here are some specific usage scenarios:

★ Urban cleaning and maintenance:

Street sweeping: used to clean up garbage, dust and other waste on city streets to keep the urban environment clean.

Sewer cleaning: equipped with professional sewage suction equipment, it can go deep into the sewer for cleaning operations to prevent blockage and pollution.

★ Industrial cleaning:

Factory waste treatment: In the industrial production process, a large amount of waste and liquid will be generated. These equipment can efficiently collect and treat these wastes to ensure the cleanliness and production safety of the factory.

Chemical leak emergency treatment: In emergency situations such as chemical leaks, it can respond quickly, carry out cleaning and recycling work, and prevent the spread of pollution.

Isuzu GIGA combination Jetting truck

★ Environmental protection and disaster relief:

Environmental protection projects: In environmental protection projects, such as river cleaning and lake management, these equipment can play an important role and improve cleaning efficiency.

Disaster relief: After natural disasters such as floods and mudslides, it can be used to clean up obstacles such as silt and garbage on the road and restore traffic and infrastructure.

★ Construction site cleaning:

Construction waste cleaning: On construction sites, a large amount of construction waste and waste is generated. These equipment can quickly clean up these wastes and keep the site clean and orderly.

Mud recovery: In operations such as earthwork excavation, mud and wastewater can be recovered for reuse or treatment and discharge.

Hydraulic cylinder, ladder, spare tire
