Myanmar Isuzu VC46 truck with palfinger SPS25000 crane

 Isuzu VC46 Palfinger truck cranes are widely used in the lifting and transportation of infrastructure materials such as municipal construction, coal mining projects, and landscaping. They can complete lifting tasks efficiently and safely in various complex environments.Equipped with 380HP 6UZ1-TCG50 engine,4600+1370mm wheelbase,palfinger SPS25000 crane, 16000kg lifting capacity.

Myanmar Isuzu VC46 truck with palfinger SPS25000 crane also called Isuzu VC46 palfinger crane truck,Isuzu VC46 GIGA truck with palfinger SPS25000 stiff boom crane,Isuzu GIGA truck with boom crane palfinger,Isuzu VC46 Palfinger boom crane truck,Isuzu truck mounted palfinger crane,etc.

The Myanmar Isuzu VC46 truck with the Palfinger SPS25000 crane is a powerful and versatile combination designed for heavy lifting and transport tasks. It is a special transport vehicle that combines the Isuzu VC46 truck and the Palfinger SPS25000 boom crane. With the reliable Isuzu truck and the powerful Palfinger crane, this combination provides efficiency, safety and versatility to handle a variety of lifting and handling tasks precisely and reliably.

The Isuzu VC46 truck crane is usually equipped with hydraulic lifting and telescopic system to achieve lifting, rotating and hoisting of goods. These operations can be performed by joystick or remote control in the cab.

Isuzu VC46 truck with palfinger SPS25000 crane
Overall Dimension		11980×2500×3980 (mm)
Gross Vehicle Weight		25000(Kg)
Curb Weight		15800(Kg)
Chassis Specification
Chassis Brand		ISUZU
Drive model		6x4
Cabin		2 seats, Left Hand Driving, with air conditional
Number of Passengers		2
Engine	Model	4-stroke direct injection , 6-cylinder in-line with water cooling, inter-cooling, EGR
	Type	6UZ1-TCG50
	Power	279KW/380HP
	Emission standard	EURO 5/6
	Displacement	9839(ml)
	Fuel type	Diesel
Gearbox		ZF 16-speed,manual
Brake System		Air break
Wheel Base		4600+1370 mm
Front/Rear Axle Loading		7000/18000(Kg)
Approach/Departure Angle		23/12(°)
Overhang		1250/3545(mm)
Tire		295/80R22.5
Max Driving Speed		90(km/h)
Superstructure Specification
Cargo Body	Dimension		8600×2300×550(mm)
	Material		Q235 carbon steel
	Cargo Thickness		Side 1.5mm, Bottom 2.5mm
Working System	Boom Type		Straight 4-Arm telescopic boom
	Crane	Crane Brand	Palfinger SPS25000
		Range of Sprayer	30m
		Max Lifting Moment	25(T.M)
		Max Lifting Capacity	16000(kg)
		Max lifting height	12(m)
		Rotation angle	360(°)
		Installation space	1150(mm)
		Recommented power	30(kw)
		Maximum working pressure	26(Mpa)
		Max Flow	63(l/min)
		Crane weight	3800(kg)
	Oil tank capacity		160(L)
	Leg	Leg type	H type
		Leg Span	2.28-5.9(m)
	Hydraulic system	Pressure	18(M pa)
		Capacity	70(l)
Other Configuration	Control system in 2 side; diamond palt, yellow warning fire; 2.5T arm, etc.
Options	Caution light, air condition, inlet valve, medicine tray, pneumatic valve, cylinder, etc.

The Isuzu VC46 truck with a Palfinger crane is a combination of a durable and reliable Isuzu commercial truck chassis equipped with a powerful Palfinger crane for heavy-duty lifting and handling tasks.

Here is an overview of the key features of the Isuzu VC46 truck and the Palfinger SPS25000 crane, as well as how the combination can be used in various applications:

Isuzu VC46 Truck:

1. **Performance**: The Isuzu VC46 is a commercial truck known for its robust performance, reliable engine, and durable construction, making it suitable for demanding transport and logistics operations.



2. **Capacity**: The VC46 has a large payload capacity and can carry heavy loads over long distances, making it ideal for transportation of goods, equipment, and materials.



3. **Durability**: Isuzu trucks are renowned for their durability and ability to withstand challenging road conditions, ensuring longevity and dependable performance.



4. **Comfort and Safety**: The truck is equipped with safety features, comfortable cabin amenities, and driver-assist technologies to ensure a secure and pleasant driving experience.



Isuzu VC46 truck with palfinger crane

Palfinger SPS25000 Crane:

1. **Lifting Capacity**: The Palfinger SPS25000 crane is a heavy-duty knuckle boom crane with a high lifting capacity, allowing it to lift and move heavy loads with precision.



2. **Reach**: The crane has an impressive reach and flexibility, enabling it to perform lifting and loading tasks in various angles and positions.



3. **Controls**: The crane is equipped with advanced controls and safety features to ensure smooth and safe operation during lifting and maneuvering.



4. **Versatility**: The Palfinger SPS25000 crane is versatile and can be used in a wide range of industries and applications, from construction and logistics to forestry and utilities.



 Isuzu VC46 GIGA truck with boom crane palfinger

Combination Benefits and Applications:

1. **Construction**: The Isuzu VC46 truck with the Palfinger SPS25000 crane is well-suited for construction sites, where heavy materials, equipment, and structures need to be lifted and transported efficiently.

2. **Logistics and Transport**: The combination is ideal for the transportation and loading/unloading of goods, containers, and machinery in logistics and transport operations.



3. **Infrastructure Development**: It can be used in infrastructure development projects, such as building roads, bridges, and utilities, where heavy lifting and precise positioning are required.



4. **Forestry and Agriculture**: The truck and crane combination can be utilized in forestry and agriculture for lifting logs, equipment, and agricultural produce with ease.



5. **Emergency Response**: The crane can also be used in emergency response situations, such as disaster relief efforts, to lift and move debris and equipment quickly and efficiently.



In conclusion, the Myanmar Isuzu VC46 truck with the Palfinger SPS25000 crane is a versatile and powerful combination that offers high performance, lifting capacity, and flexibility for a variety of heavy-duty applications. Whether used in construction, logistics, infrastructure development, or emergency response, this combination provides efficiency, reliability, and safety in handling lifting and transportation tasks.
