ISUZU Fire Trucks, ISUZU Fuel/Water Tanker Trucks, Isuzu Road Sweeper, ISUZU Garbage compactor truck: Philippine Isuzu 7 cbm vacuum tanker truck

ISUZU 7cbm Vacuum Tanker Truck is consists of a large tank for storing liquids, a strong pump for vacuuming and a series of hoses, collecting and transporting hazardous and nonhazardous liquid and semi-liquid waste.The 700P chassis is provided with ISUZU 4HK1-TC51 engine. And the power of engine is 140Kw,displacement is 5193ml,horsepower is 190hp, and transmission is Manual MLD 6-speed.The tank capacity is 7000 liters, welded from high tensile steel thick in 6mm, to vacuum suction, pressure discharge and self-flow discharge, sewer etc. HangZHou WEILONG vacuum pump driven by belt and pulley from transmission PTO.

Philippine Isuzu 7 cbm vacuum tanker truck also called Isuzu vacuum sewage suction truck, sewage vacuum pump truck,Isuzu mini vacuum tank truck, Isuzu sewage disposal trucks, Isuzu sewer tanker truck, Isuzu septic suction truck, Isuzu vacuum cleaner truck ,Isuzu vacuum suction truck,Isuzu sewage vacuum truck ,Isuzu waste vacuum truck ,Isuzu sewer truck ,Isuzu cesspit emptier ,etc.

The Philippine Isuzu 7 cbm vacuum tanker truck is used to collect, transport and discharge liquid such as dirty water,sludge,septic,crude oil and solid stuff such as small stones,bricks as well.It is suitable for cleaning the sewer,cesspit,gully ,etc. It is widely used in environment and sanitation field.

isuzu 7cbm vacuum tanker truck

With excellent talents and leading technology, we provide domestic and foreign customers with high quality products for Isuzu 7cbm Vacuum Tanker Truck,and perfect customer service. We practice strong, unyielding pioneering spirit. Then We will give our best prices to you. We wholeheartedly welcome shoppers, business associations and friends from all over the world to contact us and seek cooperation for mutual benefit. Our development is based on modern, technological, intelligent and innovative marketing services.

Vehicle Description
Overall dimensions	720022502500 mm
Gross vehicle weight	11000kg
Curb Weight	6200kg
Chassis brand	Isuzu
Traction type	4*2
Chassis Description
Chassis model	Isuzu
Cab	Singer cab, forward control type, low roof, new face, all welded steel cab of tilt type, mechanical cab tilting, rear mechanical cab suspension, adjustable driver's seat, air conditioning system, electric windows, central lock.
Traction type	LHD or RHD
Drive type	4*2
Wheelbase	4175mm
Tire specification	235/75R17.5
Tire quantity	6+1 units
Engine	Emission level	Euro5/6
	Displacement/output	5193ml / 140kw
	Horse power	190hp
Gear box	Model	China famous brand
	Number of gears	MLD,6 forward gears& 1 reverse, synchronized
Brake system	Full air brake system, split pneumatic circuit; parking spring brake acting on rear axles, exhaust brake
Axle	Front	4tons
	Rear	7tons
Tanker Description
Tanker	Capacity	7000L
	Material	6mm thickness, high quality carbon steel
	Structure	Welding, vacuum tank, Cylindrical
Pump	Type	Double vacuum pump
	Flux	68(L/S)
	Rating speed	800~1000(r/min)
	Shaft power	5(kw)
	Features	Low speed, low fuel consumption, low noise, high vacuum, high efficiency
	Manufacture	Hangzhou WEILONG Pump Co., Ltd.
Pipe	Suction and discharge pipe
Special function	Suction time ≤ 5mins, effective suction range ≥ 8, Max vacuum degree ≤ 15 KPa, dump angle ≥ 45
Standard configuration	Equipped with Inspect window,discharge valve,cleaning apparatus,5 meter long suction pipe,oil-water separators, overflow valve,etc. Cylinder vacuum tank can be lifted hydraulically to 40-45 degree. Rear door can be opened and closed hydraulically.
Optional configuration	Tanker material: stainless steel. Vacuum pump : Italy or Spain vacuum pumps. Anti-rust coating inside tank

The Isuzu 7cbm vacuum tanker truck is a vehicle specially designed for cleaning and transporting liquid waste, sewage and sludge. It is widely used in urban drainage systems, factories, sewage treatment plants, construction sites and other situations where liquid waste needs to be processed. The vehicle has a liquid storage capacity of 7 cubic meters, equipped with a powerful vacuum pump system and efficient suction, which can effectively absorb various slurries and wastewater, ensuring that the waste treatment process is efficient and clean. The Isuzu 7cbm vacuum sewage truck is very practical in cleaning sewers, cleaning sewage pools, dealing with blocked pipes and other water treatment work, and helps maintain environmental hygiene and prevent environmental pollution.

isuzu sewage suction truck Technical drawing of Philippine Isuzu 7 cbm vacuum tanker truck

The features of Isuzu 7cbm vacuum tanker truck is as follow:

Chassis Truck

ISUZU Technology

Equipped with the 4HK1-TC engine of Isuzu’s latest technology, which precisely controls fuel injection and power output, reasonably matches the 6-speed transmission and rear axle speed ratio, and the maximum vehicle speed can reach 120km/h or more to meet the needs of high-speed logistics transportation.

Reinforced Chassis Capacity

The design of the frame, axle and other assemblies is based on the premise of ensuring the carrying capacity, using high-strength materials, stamping and welding processes to achieve the lightweight design of the chassis, making the vehicle operation more economical.

Safety Drive

Equipped with large-size brakes (widened shoes), brake load-sensing proportional valves, engine exhaust brakes and other functional devices to ensure driving safety, making driving safer.

isuzu sewer truck Isuzu 7cbm vacuum tanker truck

Body Unit

Body Material

Q235 high tensile steel sheet of thickness 6 mm and side panel 5 mm thickness.

Anti-Flow Devices

-Anti-overflow Valve installed at the top of the tank, which is connected to the suction port of the pump to protect it.

-Oil/Water Separator, water vapor and oil and gas to ensure the normal operation of the engine and the vacuum pump and prolong the service life.

Vacuum System

HangZhou WEILONG, Sliding Vane.

Hydraulic System

The control valve, oil cylinder and connecting pipeline of the hydraulic system of the sewage suction truck have advanced structure, reliable performance, simple operation and convenient maintenance.
